Hydraulic Diaphragm Type Metering Pump Series

Hydraulic diaphragm type Metering pump series

FEATURES

1. The flow-through end is sealed with a diaphragm, ensuring safety and preventing leakage.

2. The metrological stability, repeatability, and linearity are all better than ±1%.

3. High-efficiency hydraulic system components, with sensitive, stable and reliable operation.

4. High-precision patented stroke adjustment mechanism, stable, reliable, and with superior performance.

5. High-precision, large-diameter check valve assembly with double-sided valve seat that can be used twice, reducing costs and increasing efficiency.

6. Optional double-layer, multi-layer or metal diaphragm, with diaphragm rupture alarm to improve safety.

7. Optional dual-head or multi-head parallel connection to increase flow rate, reduce pulse, or add in proportion.

8. An optional metering pump stroke controller can be installed to achieve automated control .

PERFORMANCE PARAMETER

●Single head flow rate: Qmax = 21000 L/h

· Pressure range: Pmax = 70 MPa

● Optional materials: 304/316L, 904, 2205, Ti, Hastelloy C wait
